I. aluminum alloy liquid tank semi-trailer is safer:
1. aluminum alloy liquid tank semi-trailer have excellent safety records in road accidents;
2. The aluminum alloy liquid tank semi-trailer has a low center of gravity, so it is easy to brake and safer;
I. aluminum alloy liquid tank semi-trailer is safer:
1. aluminum alloy liquid tank semi-trailer have excellent safety records in road accidents;
2. The aluminum alloy liquid tank semi-trailer has a low center of gravity, so it is easy to brake and safer;
3. Non-combustible materials, no sparks, lower static accumulation;
4. Less damage to the road: the government has always hoped to reduce the cost of road maintenance;
5. It can absorb the energy generated by the collision through deformation without sudden tearing;
II. The aluminum alloy liquid tank semi-trailer has lighter weight and higher payload (quick return on investment).
By reducing the weight of the vehicle body and increasing the payload, transporting the same amount of goods can reduce the number of shifts of the vehicle.
III. aluminum alloy liquid tank semi-trailer have better fuel efficiency, lower carbon dioxide emissions, and are more environmentally friendly.
IV. Longer service life of aluminum alloy liquid tank semi-trailer:
Strong corrosion resistance, 15-20 years is the typical service life of aluminum alloy semi-trailer tanker.
V. aluminum alloy liquid tank semi-trailer is more beautiful.
VI. Corrosion resistance of aluminum alloy semi-trailer tanker.
Low associated maintenance costs, no painting, durable appearance, easy to clean.
VII. aluminum alloy liquid tank semi-trailer high recycling value.
Aluminum still has a high recycling value after being scrapped.
| Item | Specification | ||
| Tank volume | 42000 liters | ||
| design standards | ADR | ||
| load media | diesel, gasoline, kerosene | ||
| Loading and unloading form | Bottom loading and unloading with top direct charging | ||
| Dimension (mm) | 12000*2550*3900mm | ||
| Total mass(kg) | 40000 | ||
| curb weight(kg) | 7000 | ||
| Rated load mass(kg) | 33000 | ||
| Cylinder material | Aluminum 5454 , thinkness 5.5mm | ||
| Head material | Aluminum alloy 5454, thinkness 6mm | ||
| Wave board | Aluminum alloy 5454, thinkness 6mm | ||
| Manhole and quantity | CIVACON brand European standard aluminum alloy explosion-proof manhole 2pcs | ||
| breathing valve | CIVACON aluminum alloy material, 2 sets | ||
| Loading and unloading | CIVACON brand bottom loading port | ||
| Oil and gas recovery | CIVACON brand with oil vapor recovery system | ||
| Anti-overflow | CIVACON brand anti-overflow system | ||
| Safety bottom valve | CIVACON brand aluminum alloy 4 inch submarine valve 2pcs | ||
| discharge valve | middle right position | ||
| Tank top rail | Segmented lifting guardrail, tank top anti-skid net | ||
| hose storage box | Stainless steel hose box, 1 piece each on the left and right sides | ||
| Discharge hose | L=6000, 3 inch steel wire oil discharge pipe | ||
| Ladder | Tank internal ladder, external ladder | ||
| toolbox | Aluminum alloy | ||
| spare tire rack | 1 unit | ||
| fender | Factory equipped aluminum alloy integral type (module stamping type) | ||
| side rail | Factory equipped aluminum alloy profiles | ||
| rear bumper | Factory equipped aluminum alloy profiles | ||
| fire protection device | 8 kg fire extinguisher, 2 pieces in total | ||
| Anti-static device | 1 piece of static-conductive mopping belt, 1 piece of static-conductive wiring board | ||
| axle | Fuhua 12 tons *3 axles | ||
| suspension | Fuwa | ||
| Leaf spring | Fuwa | ||
| Tires | 385/65R22.5 158L18PR | ||
| Rim | 22.5X11.75 rim 7 pieces | ||
| Landing gear | JOST landing gear | ||
| Kinpin | JOST 50# | ||
| lamps | 24V system, 7-core socket, LED lamps | ||
| electrical system | Explosion-proof junction box The left and right sides of the rear bumper are equipped with turn signals, brake lights, reversing lights, running lights and fog lights The wires are all sealed with bellows. |
||
| Relay valve | WABCO | ||
| ABS | WABCO’ABS | ||
| Corrosion protection | Tank inner surface cleaning ; Paint: natural finish | ||
| tank main logo | Red and blue reflective tape, both sides and tail of the tank 3M reflective stickers |
||
| trailer tools | 1 unit | ||
| Remark | pictures for reference only, logo can be customized. | ||
